RC2603 Airline Trolley
Compressed air line supply unit RL with back up trolley
Technical Data
- RB pressure reducer (of the back-up system): piston with compensator
- Demand valve: with integral alarm device and supplementary supply button
- Setting of the alarm at the demand valve and at the trolley (of the back-up system): 55 ± 5 bar
- Volume/pressure of cylinder (of the back-up system): 6 l/ 300 bar
- Number of cylinders (of the back-up system): 2
- Feeding hoses: diameter 8x17, available in different sizes (max 50 meters)
- Air reserve (of the back-up system): 3300 N litres
- Duration (of the back-up system): 110 min with an average consumption of 30 l/min and with one operator
- Switching pressure from line to back up system: 3.5 Bar
- Feeding pressure of the filtering group: Max 12 Bar
- Certified to EN 14593-1:2005 and meeting with directives 98/686/EEC (PPE) and 97/23/EC (PED)
(Note: All items subject for 10% vat)
